Input and Output terminals that interface with the PLC
Harding Intercom Head end equipment
I/O Modules for an Allen Bradley PLC system
Control Centers with 2 stations. Each station has Camera Call up monitors and multiple Camera views
Components are staged and thoroughly tested in our lab before being put in production
Brad is tracing wire paths on a service call
Fiber backbones are essential for handling the video traffic
All I/O endpoints are labled and neatly routed in our Lab
Small GE PLC Cabinet with Input/Output Terminals and Relays
Head-End Servers and Video Management/Storage
Backbone cabling is neatly routed to the equipment cabinets
Large GE PLC Cabinet with Power management and I/O
Rack mounted I/O componenets
This is an older system that contains an analog camera system integrated with modern controls
Head-End Equipment Racks upper conduits and splice box
Fiber terminations are meticuously implemented.
Rack mounted PLC componenets
Intercom Station termination equipment
Tater is waiting on the treat delivery in the warehouse
Large PLC Cabinet with I/O Modules and Relays
Our PLC equipment's power is isolated by circuit breakers in our cabinets
These cabinets are used to house all of the PLC and I/O Components
network rack components staged in our lab
